Good Quality Rail Battery Transfer Trolley With 4 Axles

  • Good Quality Rail Battery Transfer Trolley With 4 Axles
  • Good Quality Rail Battery Transfer Trolley With 4 Axles
  • Good Quality Rail Battery Transfer Trolley With 4 Axles
  • Good Quality Rail Battery Transfer Trolley With 4 Axles
  • Good Quality Rail Battery Transfer Trolley With 4 Axles
  • Good Quality Rail Battery Transfer Trolley With 4 Axles
Tempat asal Henan, Tiongkok
Nama merek BEFANBY
Sertifikasi CE,SGS,ISO9001
Nomor model KPX
Kuantitas min Order 1 Set/Set
Harga Dapat dinegosiasikan
Kemasan rincian Pabrik mobil datar listrik akan dikemas oleh terpal, bagian -bagiannya akan dikirimkan dalam kasing
Waktu pengiriman 40-50 hari seperti pengiriman biasa, 30-40 hari untuk pengiriman mendesak
Syarat-syarat pembayaran L/C,T/T,Western Union
Menyediakan kemampuan 1000 set/set per tahun
Detail produk
Bahan roda Terisolasi Kecepatan Lari 0-20m/menit
Jenis operasi Tergantung tangan + remote control Catu daya Gulungan Seluler
Kapasitas Beban 1-1000T Bahan Q235
Tinggalkan pesan
Deskripsi Produk
Good Quality Rail Battery Transfer Trolley With 4 Axles
1. Product Introduce

The battery-powered rail transfer cart utilizes a battery as its power source and features a DC motor drive system. DC motors offer smooth operation, high starting torque, and low noise levels. Operating independently of external power lines, these carts move freely along fixed rails, making them ideal for material transport across workshops, production lines, warehouses, and large industrial complexes. Depending on specific operational requirements, they can be equipped with remote controls, handheld controllers, or smart Bluetooth control systems to ensure highly efficient and safe transport operations.


Good Quality Rail Battery Transfer Trolley With 4 Axles 0

2. Successful Solution

Good Quality Rail Battery Transfer Trolley With 4 Axles 1


3. Befanby Material Handling Equipment Introduce

Good Quality Rail Battery Transfer Trolley With 4 Axles 2


Welcome to inquiry us if you'd like to learn more

4. Technique Parameter
Model KPX-2t KPX-5t KPX--10t KPX--16t KPX-20t KPX-25t KPX-30t KPX-40t KPX-50t KPX-63t
Rated load 2 5 10 16 20 25 30 40 50 63
Table size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500
Height(H) 450 450 500 500 550 600 600 650 650 750
Wheel Base 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300
Rail Inner Gauage 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter 270 300 300 350 350 400 400 500 500 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4
Ground Clearance 50 50 50 50 50 50 50 50 50 75
Running Speed 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20
Motor Power 1 1.2 1.6 2 2.2 3 3.5 4 5 6.3
Transformer Power 3 5 5 6.8 6.8 6.8 10 10 10 20
Transformer Quatity 1 1 1 1 1 1 1 1 1 1
Running Distance 80 80 80 80 80 80 80 60 50 50
Max Wheel Load 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4
Reference Weight 2.8 3.6 4.2 5.5 5.9 6.5 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50
5.Our Advantages

Good Quality Rail Battery Transfer Trolley With 4 Axles 3

As a rail-mounted transfer trolley that supports non-standard customization, the battery-powered model can be tailored to specific requirements regarding load capacity, platform dimensions, travel speed, body color, and functional needs. It can also be equipped with various features such as hydraulic lifting, roller conveyors, protective frames, weighing systems, and automatic positioning. Whether transporting molds, steel coils, structural steel, large-scale equipment, or other heavy workpieces, it offers a stable and reliable handling solution—helping enterprises boost logistics efficiency, reduce labor costs, and meet the transport demands of modern smart factories.

6.Exported Company

Good Quality Rail Battery Transfer Trolley With 4 Axles 4
Good Quality Rail Battery Transfer Trolley With 4 Axles 5
Good Quality Rail Battery Transfer Trolley With 4 Axles 6
