Best Price Mold Factory Uses Scissor Lift Material Transfer Cart
| Tempat asal | Henan, Cina |
|---|---|
| Nama merek | BEFANBY |
| Sertifikasi | CE,SGS,ISO9001 |
| Nomor model | KPJ |
| Kuantitas min Order | 1 set/set |
| Harga | Dapat dinegosiasikan |
| Kemasan rincian | Keranjang transfer akan dikemas oleh TARP, bagian -bagiannya akan dikemas dalam wadah kayu berkualit |
| Waktu pengiriman | 20-30 hari seperti pengiriman biasa |
| Syarat-syarat pembayaran | L/C, T/T, Western Union |
| Menyediakan kemampuan | 1500 set/set, per tahun |
Hubungi saya untuk sampel gratis dan kupon.
ada apa:0086 18588475571
Wechat wechat: 0086 18588475571
Skype: sales10@aixton.com
Jika Anda memiliki masalah, kami menyediakan bantuan online 24 jam.
xDetail produk
| Warna | disesuaikan | Jaminan | 24 bulan |
|---|---|---|---|
| Kapasitas muatan | disesuaikan | Catu daya | Dioperasikan listrik |
| Pelabuhan | Qingdao/Tianjin/Shanghai | Aplikasi | Industri berat, luar ruangan, konstruksi |
| Bahan | Baja |
Deskripsi Produk
Best Price Mold Factory Uses Scissor Lift Material Transfer Cart
Product Description
1. Strong Load Capacity, Sturdy and Stable
Designed specifically for mold handling, it offers a wide range of load capacities, from one to several dozen tons, easily handling large and medium-sized molds.
The scissor mechanism is constructed of high-strength steel, ensuring smooth lifting and lowering, ensuring the transport of materials at various heights.
2. Precise Lifting, Seamless Integration
Equipped with either a hydraulic or mechanical lifting system, it offers simple operation and customizable lifting heights, enabling seamless integration with production lines, workbenches, and other equipment.
3. Ultimate Maneuverability, Free-Rotation
Equipped with high-performance, non-slip, and wear-resistant cast steel wheels (optional and customizable), it offers lightweight maneuverability and a tight turning radius, enabling it to maneuver even in narrow workshop aisles.
Product Parameter
| Model | KPT-2T | KPT-5T | KPT-10T | KPT-16T | KPT-20T | KPT-25T | KPT-30T | KPT-40T | KPT-50T | KPT-63T | KPT-80T | KPT-100T | KPT-150 | |
| Rated load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table Size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Heigth(H) | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 700 | 800 | 900 | 1000 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rai Ilnner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Dia.(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | |
| Wheel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed(mm) | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power(kw) | 0.8 | 1.5 | 1.5 | 2.2 | 2.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | |
| Running distance(m) | 25 | 25 | 25 | 25 | 30 | 30 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Wight(t) | 2.5 | 3.5 | 4 | 5.2 | 5.6 | 6.2 | 6.5 | 7.3 | 7.8 | 10.5 | 12.3 | 14.1 | 26.2 | |
| Recommend Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 |
QU100 |
|
Products Deatils
Product Feature
Shipping
Company Profile
Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd. is a professional and international handling equipment company integrating R&D, design, production and sales. It has a modern management team, technical team and production technician team.
Founded in September 2003, the company is located in Xinxiang city, Henan province, covering an area of 33,300 square meters. It has a modern large-scale factory building, world-advanced production equipment and office equipment. The company has more than 150 employees, including 8 engineers and more than 20 technicians. The company has a first-class research and design team, which can undertake the design and production of various non-standard handling equipment.
BEFANBY can not only provide transfer cart quotations, but also provide you with satisfactory handling solutions.
Related Products
We can customize different types of models according to the actual needs of customers. The table can be equipped with a variety of special devices, such as rollers, chain plates, chains, lifting, etc. The size and tonnage of the table can be adjusted according to the conditions of the transported materials.
